As-built survey for an architecture team with DWG, DXF, and IFC delivery

An architecture team needed a digital baseline for an existing building that could move directly into CAD and BIM workflows. The goal was a usable delivery, not a visual-only model.

  • DeliveredDWG · DXF · IFC
  • Use caseAs-built & design
  • EvidenceViewer + orthophoto
CAD-style edge drawing of a real building model
Edge drawing · real modelExample from another real project – not the building of this case study.

Project context

Client
Architecture and planning office
Engagement
As-built capture for renovation and concept planning

Challenge

  • The team needed reliable existing-building data for several downstream disciplines, not just a visual 3D asset.
  • On-site measuring and manual modeling would have stretched the planning lead time.
  • The output had to support both technical drawings and BIM-oriented deliveries.

Approach

  1. Define the building scope and downstream targets for AutoCAD, DWG, and IFC workflows.
  2. Reconstruct geometry from drone captures with focus on planning-relevant structures.
  3. Package delivery around the actual planning process instead of a generic 3D export bundle.

Delivered files

  • DWG and DXF delivery for technical drawings
  • IFC-oriented data basis for BIM deliveries
  • Viewer link and orthophoto for stakeholder review

Outcome

  • Faster start into design, coordination, and downstream planning.
  • Less ambiguity because geometry and deliveries arrived in a structured form.
  • An example that demonstrates the value of drone imagery for architecture workflows.

As-built survey with usable DWG, DXF, and IFC deliveries for CAD and BIM planning.
